In 1944, U.S. Navy launched a competition that called for a large rescue helicopter which could carry up to 10 occupants. McDonnell was determined to win a new Navy contract as the company only had sub-contract jobs at the war time. With investment in Platt LePage Aircraft Co., McDonnell was allowed to learn helicopter techniques and developed its own design, Model 65. Considering a most suitable configuration for a large helicopter, it was fitted with twin side-by-side rotors mounted at the end of main wings. In 1945, McDonnell proposed the project to Navy and was rewarded contract for construction of one test bed, designated XHJD-1. First flight was made on April 1946. It became the world's first successful twin-engines, twin rotors helicopter. From 1946 to 1951, XHJD-1 was tested for numerous flying researches peculiar to its twin-rotor configuration. Upon completion of its trails program, the XHJD-1 was then retired and was donated to the National Air and Space Museum.

Type:

Purpose:

Rotor dia.:

Length:

Height:

Engine:

Max.speed:

Crew:

Armament:

Experimental transport helicopter

To research tandem rotors configuration

50ft.

32ft.2in.

13ft.6in.

2x Pratt & Whitney R-985-AN-14B radial

120 mph

2

None
